PARTS PICTURE
1
Steering Wheel Cap
2
Lock Nut - 2
3
Steering Wheel
4
Turn Signal
5
Dash
6
Steering Column
7
Battery Retainer
8
6 Volt Battery
9
Seat
10
Handle
11
Vehicle
12
Steering Column Cover
13
6 Volt Charger
14
Key
Not Shown
Label Sheet
#8 x ¾
" Screw - 2
Assembly Tool
1
3
4
5
6
8
2
7
9
10
11
12
2
13
14
