• Fit the remaining lock nut onto the end of the steering column.
• Tighten the lock nut with the assembly tool.
Lock Nut
• “Snap” the steering wheel cap into the center of the
steering wheel.
Steering
Wheel Cap
End of Steering Column
10
11
ASSEMBLY
• First, “snap” the front of the seat to the vehicle A .
• Next, “snap” the four tabs near the back of the seat into the
matching slots in the vehicle
B
.
12
B
SIDE VIEW
A
• Using a slotted screwdriver, turn both lock fasteners ¼ turn to
the locked position .
LOCKED UNLOCKED 13
