Fender 65 Super Reverb -Amp User Manual

Page 7

background image

w

ww

ww

w.

.f

f e

e n

n d

d e

e r

r.

.c

co

om

m

w

ww

ww

w.

. m

m r

r g

g e

e a

a r

r h

h e

e a

a d

d .

.n

ne

et

t

7

TYPE: PR

469

PART NUMBERS:

021-7600-000, 120V, 60Hz (USA),

021-7660-000, 230V, 50Hz (Europe),

021-7640-000, 230V, 50Hz (UK),

021-7630-000, 240V, 50Hz (Aust),

021-7670-000, 100V, 50-60Hz (Japan)

POWER REQUIREMENTS:

270W

FUSE TYPE:

100V-120V models:

3A, fast-blow, 125V minimum,

230-240V models:

1. 6A, fast-blow, 250V minimum,

IMPEDANCES

Inputs 1:

1M ohms (both channels)

Inputs 2:

136K ohms (both channels)

Output: 2

ohms

SPEAKER COMPLEMENT:

Four 10 in. (25.4 cm) vintage reissue, P/N 055613

DIMENSIONS

Height:

24 7/8 in.

(63. 2 cm)

Width:

25 1/8 in.

(63. 8 cm)

Depth:

10 1/2 in.

(26. 7 cm)

WEIGHT:

65 lbs.

(24. 3 kg)

Product Specifications are subject to change without notice.

S

S

S

S

p

p

p

p

e

e

e

e

c

c

c

c

ii

ii

ff

ff

ii

ii

c

c

c

c

a

a

a

a

tt

tt

ii

ii

o

o

o

o

n

n

n

n

s

s

s

s

R. IEC POWER SOCKET - The line cord must be

connected to a grounded AC receptacle in accor-
dance with the voltage and frequency ratings as
specified on the rear panel of the unit.

S. FUSE - Replace a blown fuse only with a fuse of the

type and rating as specified on the rear panel of the
unit. If the amp repeatedly blows fuses, have the unit
tested by an authorized Fender service technician.

T. POWER - Switches the unit ON and OFF.

U. STANDBY - In standby mode, power is supplied only

to the tube filaments to keep them warm and ready
to operate. Use standby during short breaks to
eliminate warm-up time and extend the life of the
tubes.

V. MAIN SPEAKER JACK - This is the primary speaker

connection. Speakers (internal or external) must
always be connected here while operating the unit.

W. EXTERNAL SPEAKER JACK - Plug in external

speakers here. This jack is wired in parallel with the
main speaker jack.

*** NOTE: The amp is optimized for a 2 ohm speaker

load, which is the rating of the internal speaker
configuration. If a speaker load other than 2 ohms is
used, the amplifier will distort before reaching
maximum output, and the life of the tubes will be
reduced. Two external 4 ohm speaker cabinets
would provide the recommended 2 ohm load.

X. FOOTSWITCH - Plug the included footswitch in here

to enable remote on/off switching of Reverb and
Vibrato.

*** NOTE: Vibrato will NOT work without the footswitch

connected, but the reverb effect will.

Y. REVERB OUTPUT / INPUT - RCA jack connections

for routing the reverb signal to and from the reverb
pan.
