G–DEC 30 MIDI Configuration
In Utility Mode you can set MIDI CONTROL (menu 9) to SYNTH
or AMP. If set to AMP, data sent on MIDI channel 16 will control
the amp, and channels 1-15 will be routed to the synth. This
will present a problem if a normal MIDI song is played with
music on channel 16 (which could affect the amp settings in
unexpected ways). In this case you can either delete channel
16 or move it to a different channel. If MIDI CONTROL is set
to SYNTH, all MIDI data will be routed to the synth. When
songs are created in the COMPOSE Mode, program changes
will be saved in the song on channel 16 regardless of the MIDI
Amp Control setting, but the program changes will only work
during playback if the amp is set to AMP. MIDI on channel
16 is also passed from the MIDI input jack to the DSP during
playback of songs or patterns if the MIDI CONTROL is set to
AMP.
GDEC30 MIDI Controls
If the MIDI CONTROL is set to AMP the following commands can be used (on CH 16).
Amp Control Control Type Value Range
Preset Num Program Change 0-99,127=Tuner
Amp Volume CC#07 0-127
Synth Volume CC#11 0-127
Start/Stop MIDI CC#85 Don’t care
Play CC#86 Don’t care (Ignored if the
amp is busy playing a
pattern or song)
Record CC#87 Don’t care (Ignored if the
amp is busy playing a
pattern or song)
Overdub CC#88 Don’t care (Ignored if the
amp is busy playing a
pattern or song)
Data Increment CC#96 Don’t care
Data Decrement CC#97 Don’t care
Amp Gain CC#102 0-127
RVB Level CC#108 0-127
FX Level CC#110 0-127
FX Param1 CC#111 0-127
FX Param2 CC#112 0-127
FX Param3 CC#113 0-127
FX Param4 CC#114 0-127
Select Song CC#119 0-63 (Ignored if the amp
is busy playing a pattern
or song)
