4
FTP-622MCL301/302
NOT FOR NEW
DESIGN
MCL301
MCL302
3-M3 FIXING HOLE FROM UPPER SIDE
2-M 3 burring (FIXING HOLE FROM BOTTOM SIDE)
235
± 15
14.2
42
67.7
± 1
(70.8)
(78.6)
58.4(POSITIONING HOLE)
45.0
(97.3)
(49.5) 47.8 ± 1
13.3
38.5
3—2.0 or less
300
± 15
Note: all dimensions are nominal value.
(2 or less)
(47.2)
PAPER
INSERTION
PAPER
INSERTION
2 or less
Unit: mm
Mechanism with cutter
