FTP-622MCL301/302
NOT FOR NEW
DESIGN
Power supply
Dimensions
Part number
FTP-622MCL301/302
Interface
Centronics (ESC/POS
TM
), RS232C
24VDC
±
5%, Voltage
Current : average
*2
(
): Peak
For head
0.87 (1.16) A (at 80 mm/s printing speed, 25% printing ratio)
0.63 (1.16) A (at 50 mm/s printing speed, 25% printing ratio)
0.58 (0.58) A (at 30 mm/s printing speed, 25% printing ratio)
For motor
24VDC
±
5%, 1.0 A maximum
For cutter
24VDC
±
5%, 1.0 A maximum
For logic
5VDC
±
5%, 0.5 A maximum
Mechanism (cutter)
101 (W)
×
70 (D)
×
42 (H) mm (w/cutter)
Interface board
131 (W)
×
89 (D)
×
24 (H) mm
Weight (Mechanism+Cutter)
approximately 300 g (w/cutter)
Pulse durability : 1
×
10
8
pulse/dot (using Fujitsu's standard
Mechanism driving method)
Expected life
Wear resistance: 50 km (at 25% printing ratio)
Cutter
3
×
10
5
cuts
Operating temperature
0 to +50
°
C
*3
Operating humidity
20 to 85% RH (no condensation)
Storage temperature
–20 to +60
°
C (excluding paper)
Storage humidity
5 to 95% RH (no condensation)
Head temperature
By thermistor (applied energy control, abnormal temperature detection)
Detection
Paper out/Mark detect
By photointerrupter
Head-up
By microswitch
For front insertion use (58 mm width)
: FTP-020PU001,FTP-020P0701
For rear insertion use (60 mm width)
: FTP-020P0020,FTP-020P0702
*Recommended papers
· Oji Paper
: PD150R,PD160R,PD170R
· NIPPON Paper
: TF50KS-E,TF60KS-E,TF60KJ-R
· MITSUBISHI Paper Mills
: P220VBB-1,AFP-235
Specifications
Item
(Continued)
Environmental
conditions
Recommended thermal sensitive paper
*1: There may be exceptions.
*2: 24VDC, minimum head resistance.
*3: Guarantee: +5
°
C ~+40
°
C.
