-3- 595-5345-07
7a - Mount with Double Sided Tape
❐
Install the battery cover.
❐
Peel the protective backing from one side of two pieces of the double sided
tape, and apply the tape to the areas on the back of the transmitter as shown
in Figure 4.
❐
Remove the remaining protective backing. Carefully stick the transmitter to
the exact location marked in step 6.
7b - Mount with Screws & Hollow-Wall Fasteners
❐
Temporarily remove the batteries.
❐
Hold the transmitter in the desired location, and mark the two mounting holes.
❐
Set the transmitter aside. Drill two 7/32 inch mounting holes. Tap the hollow-
wall fasteners into the two holes.
❐
Hold the transmitter in place, and secure with the two screws.
❐
Reinstall the batteries and the battery cover.
Double
Sided Tape
Double
Sided Tape
Mounting Holes
Figure 4
Figure 5
5. Adjust the Microphone Sensitivity so that it is at the least sensitive position
to reliably activate the transmitter. If the sensitivity is set too high, it may false
trigger on common household noises.
6. When the system is working properly, carefully mark the desired location of
the Extension Transmitter, and go to step 7 for final installation.
