Audio dubbing (only for vm-8500la) – Hitachi VM7500LA User Manual

Page 45

Text mode
Original mode

AUDIO DUBBING (only for VM-8500LA)

- 45 -

4. Press "TITLE" to erase the display from the viewfinder.

Chart of characters available in the titler

A B C D E F G H I J K L M N 0 P Q R
S T U V W X Y Z 0 1 2 3 4 5 6 7 8 9
? ' . / , - ; : < > !

AUDIO DUBBING (only for VM-8500LA)

The audio dubbing feature lets you record new audio (sound) on a previously recorded tape without erasing the
original video (picture).
When you audio dub a tape, the previous audio is erased and replaced with new sound.

NOTES:
• Sound from the built-in microphone and the AUDIO jack can be dubbed.
• When dubbing audio from the built-in microphone, set "AV OUT/IN" to "OUT" and do not connect the
"AUDIO" jack. When dubbing from the "AUDIO" jack, set "AV IN/OUT" to "IN".

1. Insert a recorded tape.
Be sure that the record safety tab is not missing.
2. Place "CAM/OFF/VIDEO" to "VIDEO" position.
