SPECIFICATIONS
Power Unit with Sweeper A
ttached
Model
* Sweeper angle set straight ahead
Low range @ 2-112 or 3-112 inches Cutting height settings
763.8 Ib 743.8 Ib 638.4 Ib Dry weight
61 inch Overall width*
43-1/2 inch Overall height
88-1/4 inch 85-3/8 inch Overall length*
CPH3 CPH2 CPH1 Description code
HRC7020ZMA H RC70 1 8ZXA HRC7013K1 ZXA
Sweeper
Model
5 oz Gear box oil capacity
12-inch Gear box driven pulley
2: 1 Gear box ratio
Clockwise (viewed from the drive chain side) Broom rotation
32 Brush wafer spacers
33 Brushes
Polypropylene Broom material
1/2-inch from brissel to chain wafer retainer disc Broom service limit
20 inches Broom diameter
54 inches @ 0
o
tilt angle, 49 inches @ 25
o
tilt angle Sweeping width
2 ~ 4 inches Broom contact width
14/45 Drive/driven sprocket teeth
42 links, 1/2-link, and master link Drive chain length
#50 roller type Drive chain
12.5
o
and 25
o
both right or left Tilt angles
FS3 Description code
FS7054
32
FS7054 FRONT SWEEPER
