English – 41
TECHNICAL DATA
Bar and chain combinations
The following cutting attachments are approved for the models Husqvarna 385XP, 385XPG, 390XP and 390XPG.
The combinations below are not CE–type approved, but are recommended for 390XP/XPG on markets outside of
Europe, which do not demand special type approval.
Saw chain filing and file gauges
Bar Chain
Length, inch Pitch, inch Gauge, mm Max. nose radius Type
Length, drive links
(no.)
18 3/8 1,5 11T
Husqvarna H42,
Husqvarna H48,
Husqvarna H81
68
20 3/8 1,5 11T 72
24 3/8 1,5 11T 84
28 3/8 1,5 11T 92
Bar Chain
Length, inch Pitch, inch
Max. number of teeth on tip sprocket /
radius of tip sprocket
Type
24 0,404 34 mm
Husqvarna H64
28 0,404 34 mm
32 0,404 42 mm
36 0,404 42 mm
