ASSEMBLY
11 F−98857
ASSEMBLY
Read and follow the assembly and adjustment instructions for your
mower. All fasteners are in the parts bag. Do not discard any parts
or material until the unit is assembled.
WARNING: Before doing any assembly or mainte-
nance to the mower, remove the wire from the spark
plug.
NOTE: In this instruction book, left and right describe the loca-
tion of a part with the operator on the seat.
NOTE: Torque is measured in foot pounds (metric N.m). This
measurement describes how tight a nut or bolt must be. The
torque is measured with a torque wrench.
TOOLS REQUIRED
Pliers (1)
Adjustable open end wrenches (2)
Blade type screwdriver (1)
Phillips screwdriver (1)
PARTS BAG − CONTENTS
The fasteners and other loose parts are shown below. The fasteners are shown full size. The quantity is shown in brackets ( ).
ÎÎ
1x66
(1) Hex Bolt
1x45
(2) Hex Bolt
18x16
(2) Lockwasher
20729
(1) Keys & Ring
15x118
(1) Flange Nut
17x195
Washer
30x49
Hair Pin
6x99
(2) Bolt
14x79
(2) Wingnut
