English – 23
TECHNICAL DATA
Technical data
Note 1: Noise emissions in the environment measured as sound power (L
WA
) in conformity with EC directive 2000/14/EC.
Note 2: Equivalent sound pressure level is calculated as the time-weighted energy total for sound pressure levels under various working
conditions with the following time distribution: 1/2 idling and 1/2 max speed.
EC-declaration of conformity (Applies to Europe only)
Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declare under sole responsibility that the hedge trimmers
Husqvarna 325HDA65, 323HE3, 325HE3 and 325HE4 from 2002's serial numbers and onwards (the year is clearly stated in plain text
on the type plate with subsequent serial number), are in conformity with the standards or or other normative documents following the
provisions in the COUNCIL'S DIRECTIVES:
- of June 22, 1998 ”relating to machinery” 98/37/EC, annex IIA.
- of May 3, 1989 ”relating to electromagnetic compatibility” 89/336/EEC, and applicable supplements.
- of May 8, 2000 ”relating to the noise emissions in the environment” 2000/14/EC. Conformity assessment according to Annex V.
For information relating to noise emissions, see the chapter Technical data. The following standards have been applied: EN ISO 12100-
2, CISPR 12:1997, EN774
SMP Svensk Maskinprovning AB, Fyrisborgsgatan 3, SE-754 50 Uppsala, Sweden, has carried out voluntary type approval for
Husqvarna AB. The certificates have the numbers: SEC/00/789, 01/094/012 - 325HDA65, SEC/05/1050, 01/094/002 - 323HE3, SEC/
00/790, 01/094/002 - 325HE3, SEC/00/791, 01/094/001 - 325HE4
Huskvarna, 25 November 2006
Michael Kullberg, Business manager
Technical data 325HDA65 323HE3 325HE3 325HE4
Engine
Cylinder displacement, cm 3 24,5 24,5 24,5 24,5
Cylinder bore, mm 34,0 34,0 34,0 34,0
Stroke, mm 27 27 27 27
Idle speed, rpm 2700 2700 2700 2700
Recommended max. speed, rpm 11000-12600 11000-12600 11000-12600 11000-12600
Max. engine output, acc. to ISO 8893 0,8/9000 0,8/9000 0,8/9000 0,8/9000
Catalytic converter muffler Yes Yes Yes Yes
Speed-regulated ignition system Yes Yes Yes Yes
Ignition system
Manufacturer/type of ignition system
WalbroMB/
SEM AM49
WalbroMB/
SEM AM49
WalbroMB/
SEM AM49
WalbroMB/
SEM AM49
Spark plug NGK BPMR 7A NGK BPMR 7A NGK BPMR 7A NGK BPMR 7A
Electrode gap, mm 0,5 0,5 0,5 0,5
Fuel and lubrication system
Manufacturer/type of carburettor Zama C1Q Zama C1Q Zama C1Q Zama C1Q
Fuel tank capacity, litre 0,5 0,5 0,5 0,5
Weight
Weight without fuel, kg 5,9 5,8 6,0 6,2
Noise emissions
(see note 1)
Sound power level, measured dB(A) 108 104 104 105
Sound power level, guaranteed L
WA
dB(A) 110 110 110 107
Sound levels
(see note 2)
Equivalent noise pressure level at the operator’s ear,
measured according to EN/ISO 11806 and ISO 7917, dB(A):
97 94 92 91
Vibration levels
Vibration levels at handles, measured according to
EN/ISO 11806 and ISO 7916, m/s 2
Idle speed, front/rear handles: 3,2/1,5 3,4/1,5 1,3/2,1 2,2/1,8
Max. speed, front/rear handles: 6,6/7,1 5,1/8,0 3,0/5,9 5,9/4,8
Blades
Length, mm 650 550 550 550
Blade speed, cuts/min 4184 4184 4184 4184
