Accessories
Check to make sure you have the following accessories before disposing of the packing material.
For optional accessories, please access our web site at: www.hitachi.us/tv
Ceiling mounting is not recommended. Mounting the panel on the ceiling does not provide adequate ventilation •
for the electronics or proper support for the front glass panel. This LCD television product is designed for a
maximum tilting angle of 45 degrees from vertical.
Please see page 8 for important information related to wall mounting. •
REMOTE CONTROL BATTERY INSTALLATION AND REPLACEMENT
The remote control operates on 2 “AA” batteries.
Open the battery cover of the remote control by pushing and sliding it in the direction of 1.
the arrow.
Insert two new “AA” size batteries for the Remote Control. When replacing old batteries, 2.
push them towards the springs and lift them out.
Match the batteries to the (+) and (-) marks in the battery compartment. 3.
Insert the bottom of the battery, the (-) side, into the battery compartment first, push 4.
towards the springs and insert the top of the battery, the (+) side, into place. Do not force
the battery into the battery compartment.
Close the battery cover by sliding back the cover and push the cover until it clicks shut. 5.
w “AA” Size
Batteries (2)
e Power Cord q Remote Control Unit
CLU-4591AV
(Part No. HL02631)
Do not insert batteries with ‘+’ and ‘-’ polarities reversed as this may cause the batteries to swell or rupture •
resulting in leakage.
Never mix used and new batteries in the device. •
Replace all the batteries in the device at the same time. •
Remove the batteries if the remote control is not going to be used for an extended period of time. •
CAUTION
CAUTION
r Operating
Guide
t Easy Graphic Guide  Stand Screw (4)
L32A403 : T4x14
L42A403 : M6x10
Easy Graphic Guid e
OPERATING GUIDE
ÍMPORTANT: ÉTEINDRE TÉLÉVISION ET TOUTES AUTRES COMPOSANTES EXTERNES AVANTE DE DEBRACHER OU DE DÉBRANCHER TOUT CÂBLE.
GUIDE D’OPÉRATION
IMPORTANTE: APAGAR EL TELEVISOR Y LOS EQUIPOS EXTERNOS ANTES DE CONECTAR O DESCONECTAR LOS CABLES.
GUIA DE OPERACION
*Image may differ from actual product.
www.hitachi.us/tv 1-800-Hitachi (1-800-448-2244)
Side Jacks
Side Controls
AV IN2
HDMI 3
HDMI 4 SERVICE
AV2
Rear Jacks
AIR/CABLE DIGITALOUT R B G
A V 1
RGB
HDMI 1 HDMI 2
NEED MORE INFO ON THE DTV TRANSITION? See page 34 in this Operating Guide and please visit www.dtvtransition.org
READ THE ENCLOSED INSTRUCTIONS CAREFULLY. KEEP THIS OPERATING GUIDE FOR FUTURE REFERENCE. Record the model name and serial number of your LCD Television for future reference.
MODEL NAME. ____________________ SERIAL NO. ________________________
This information is located on the back and right side of the television.
