26

Audio

Select AUDIO to adjust the sound to your preference.

Sound Mode

This function has four sound settings which are preset according

to the type of program. Standard for normal audio condition,

Movie audio settings for a movie, News audio setting for News

Broadcast programs and Custom mode is adjusting audio levels at

your convenience. Only on Custom mode you are able to change

settings. The other three modes will have unavailable settings

grayed out.

Audio Menu Settings Adjustment

Press the CURSOR PAD

1.

or to select menu item.

Press the CURSOR PAD

2.

or to adjust the function.

Press EXIT to quit the MENU, or select AUDIO to return to the

3.

main menu.

If TREBLE is selected you are adjusting treble. The

additional menu items BASS and BALANCE can be

selected and adjusted in the same manner.

Bass

This function controls the low frequency audio to the speakers.

Treble

This function controls the high frequency audio to the speakers.

Balance

This function will control the left to right balance of the LCD TV

internal speakers and headphone jack.

Audio Source

Multi-Channel Television Sound will allow you to select STEREO (a

stereo broadcast), MONO (monaural sound) used when receiving

a weak stereo broadcast or SECOND AUDIO PROG (SAP) which

may be a secondary language, weather report, etc. This setting is

only for analog programing.

Preferred Language

Some programs transmit in other languages. This language function

will allow you to set between 3 language options (English,Español

& Français) to your preference as the audio default language.

Audio Language

Some programs transmit more than one DTV language option. Most

will have English as a default language. The language function will

allow you to select up to 6 language options (if available). Please

try all available options.

Digital Output

This function allows you to select between RAW and PCM. This

setting changes the format of the Digital Optical Output.

NOTE

PCM.- Select this feature if the TV is connected to an amplifier/

receiver with a PCM only decoder; it will provide two independent

soundtrack channels through the optical audio output jack (Digital

Audio).

RAW.- Select this feature to allow the original audio bit stream to

be passed through to the audio receiver.

Internal Speakers

This function is useful when using external speakers. Select ON if

using the internal speakers only. Select OFF if you prefer to use the

speakers from a separate stereo system.

Perfect Volume

This function will automatically adjust volume so each channel and

input has the same average volume level.

SRS TruSurround HD

Provides enveloping, immersive surround sound, for every seat

in the room, done with only two speaker, eliminating the need for

multiple external speakers. This is often done to create a more

realistic audio environment.

Use CURSOR

1.

to select On/Off option.

Off : Turns off the surround sound effect.

On: : Provides the surround effect by simulating two or more

speakers to the rear of the listener.

Reset

This function allows you to Reset the Audio Menu Settings of

the present input and return it to the Custom mode and default

settings.

Use the CURSOR PAD

1.

, to highlight functions.

Press the SELECT button or the CURSOR PAD

2.

to select

Yes or No.

Press the SELECT button on the Yes option to execute the

3.

reset of the Audio settings.

You can customize each of the Audio Inputs to your preference

to increase audio performance and pleasure, depending upon the

audio program being heard. If RESET is selected, only the selected

Input will reset to the initial conditions as explained above.

If RESET is selected in Input 1, only Input 1 will return to factory

conditions.

Video

Audio

Treble

Select

SEL

Channels

Sound Mode

Balance

Setup

Bass

Audio Language

Preferred Language

Digital Output

50

Custom

RAW

0

50

EXIT

Exit

Move

Return

Español 1

English

Video

Audio

Select

SEL

Channels

Setup

Digital Output

EXIT

Exit

Move

Return

Audio Language

Preferred Language

RAW

Español 1

English

Internal Speakers

SRSTruSurround HD

Reset

Perfect Volume

On

On

On
