15
Title: E. Control Box Assembly Model: F-450MAH(-C)
Index
No. Description
Material or
Model Number Part Number
Required Number
L-0
M-0
to
S-0
S-1
to
V-0
V-1
to
V-3
A-0
A-1
Control Box Assembly
Order Assembly Parts Individually
2A0953A01 1 1 -
2A0953A02 1 -
2A0953A03 1 1
1 Control Box Cover 3A0411-01 1 1 1 1 1
2 Water Control Relay 24VAC 406132-03 1 1 1 1 1
3 Gear Motor Relay 24VAC 406133-04 1 1 1 1 1
4 Circuit Protect Relay 240VAC 418271-05 1 1 1 1 1
5 Gear Motor Protect Relay 120VAC 418271-03 1 1 1 1 1
6 Transformer 4A0557-01 1 1 1 1 1
7 Start Relay(Starter) 4A1107-11 1 1 1 1 1
8 Start Capacitor 243-292MFD,
115VAC 3A0076-10 1 1 1 -
243-292MFD,
165VAC 3A0076-20 1 1
9 Run Capacitor 15MFD,
370VAC 439943-04 1 -
15MFD,
370VAC 3A2005-08 1 1 -
35MFD,
440VAC 3A2005-12 1 1
10 Strap 434580-10 1 -
4A2262-02 1 1 1 1
11 Gear Motor Capacitor 12MFD,
330VAC 4A0894-01 1 1 -
20MFD,
350VAC 4A4319-01 1 1 1
12 Rocker Switch 4A0558-01 1 1 1 1 1
13 Toggle Switch 4A2332-01 1 1 1 1 1
14 Fuse Holder 4A0892-01 1 1 1 1 -
4A3449-01 1
15 Fuse AGC-1, 1A,
250V 4A0893-01 1 1 1 1 1
16 Control (Timer) Board 437305-01 1 1 1 1 1
17 Board Support 4A0336-03 4 4 4 4 4
18 Drain Timer 4A0889-01 1 1 1 1 1
19 Fan Motor Capacitor 5MFD,
250VAC 443192-02 1 1 1 1 1
20 Fuse Holder 4A0892-02 1 1 1 1 -
4A3449-02 1
21 Fuse 1.5A 4A0893-04 1 1 -
2.0A 4A0893-05 1 1 1
