Title: C. Refrigeration Circuit Model: F-450MAH(-C)
Index
No. Description
Material or
Model Number
Part Number
Required Number
L-0
to
P-0
P-1
to
S-0
S-1
to
V-0
V-1
to
V-3
A-0
A-1
Refrigeration Circuit
Order Assembly Parts Individually
2A0926A01 1 1 1 -
2A5930A01 1 -
2A5930A02 1
1 Compressor RS43C2E-CAA-219 4A2300-01 1 1 1 -
RST45C1ECAA-202 4A4479-01 1 1
1a Grommet 434403-01 4 4 4 -
4A2593-01 4 4
1b Spacer 434404-01 4 4 4 -
4A2595-01 4 4
1c Bolt 8×45 437889-01 4 4 4 4 4
2 Protector 4A1805-01 1 1 1 -
4A4481-01 1 1
3 Protector Holder 437339-01 1 1 1 -
4 Terminal Cover 4A4479F01 1 1
5 Spring Clip 4A4479F02 1 1
6 Condenser 2A0923-01 1 1 1 1 1
7 Shroud 2A0908-01 1 1 1 1 1
8 Fan Motor Bracket 3A0828-01 1 1 1 1 1
8a Hex Head Bolt w/Washer 5×12, SS 7B0230512 4 4 4 4 4
9 Fan Motor 440911-01 1 -
4A3158-01 1 1 1 1
9a Self-Locking Nut 7N21I0832 4 4 4 4 4
10 Fan Blade 444898-01 1 1 1 1 1
11 Drier 4A1113-01 1 1 1 1 1
12 Expansion Valve 4A4493-01 1 1 1 1 1
13 Expansion Valve Cover 4A1168-01 1 1 1 1 1
14 High-Pressure Switch 433441-05 1 1 1 -
463180-05 1 1
15 Expansion Valve Bulb Holder 3A0112-01 1 1 1 -
3A0107-01 1 1
16 Clamp 443461-01 1 1 1 1 1
