13
Title: D. Water Circuit Model: F-450MAH(-C)
Index
No. Description
Material or
Model Number Part Number
Required Number
L-0
M-0
N-0
to
A-1
Water Circuit
Order Assembly Parts Individually
2A0942A01 1 1
1 Water Valve Bracket 3A0553-01 1 1
2 Water Supply Pipe 4A0891G01 1 1
3 Washer 4A0867-01 1 1
4 Inlet Water Valve 4A0865-01 1 1
5 Drain Valve Bracket 4A1264-01 1 1
6 Drain Valve 4A2077-01 1 -
4A2772-01 1
7 Reservoir 2A0753-01 1 1
8 Float Switch 435490-01 1 1
9 Reservoir Cover 214810-01 1 1
10 Reservoir Inlet 4A0869-01 1 1
11 Drain Fitting 4A0776G01 1 1
12 Reservoir Separator 4A1255-01 1 1
13 Reservoir Hose 4A1165-05 1 1
14 Silicone Hose L=230 7730I3896 1 1
15 Vinyl Hose L=65 7716-0913 1 1
16 Vinyl Hose L=270 7716-2025 1 1
17 Vinyl Hose L=80 7716-2025 1 1
18 Vinyl Hose L=355 7725-1923 1 1
19 Tee 4A1331-01 1 1
20 Silicone Hose L=340 7730-1822 1 1
Clamps
Hose Clamp 4A2017-01 5 5
Hose Clamp 4A2017-02 1 1
Hose Clamp 4A2017-08 5 5
Hose Clamp 4A2017-05 1 1
Hose Clamp 4A2017-06 1 1
