OPERATION BAGGER CART
CONNECTING AND DISCONNECTING THE CART
Connection
1.
2.
3.
,
Stop the engine, and set the parking brake.
Connect the bagger cart to the tractor, using
two clevis pins and two safety clips, as
shown.
HITCH BRACKET
SAFETY CLIP (2) CLEVIS PIN (2)
Install the middle chute assembly by inserting the flexible end into the connecting sleeve and placing
the other end on the lower chute.
Position the middle chute assembly so the window faces the driver’s seat.
Attach the two upper hooks to the hook loops on the connecting sleeve.
Attach the lower hook to the hook loop on the lower chute.
Disconnection
Disconnect the bagger cart from the tractor in the reverse order of connection.
