ASSEMBLY

BAGGER CART

18.

Connect the cart to the tractor, using two clevis
pins and two safety clips, as shown.

HITCH BRACKET

(2)

CLEVIS
PIN

(2)

Chute

Assembly

19.

Drill

an 11/32 inch (8.5 rnrn) hole in the lower

chute,

shown.

LOWER

CHUTE

FOR 38" DECK:

Drill

the

hole at a point 10 inches (255

rnm)

from

the

end

the chute and

2-3/4 inches

(70

mm)

outside the seam line.

LOWER CHUTE

FOR

42"

and

DECKS:

Drill the hole at a point

inches

(240

mm)

from the end of the chute and 1-1/2 inches

(40

mrn)

inside the

seam

line.

20.

Install a figure-8 hook

loop

on the lower chute,

using a

x 314 inch pan-head screw,

inch flat washer, and

inch lock nut.

Position the figure-8 hook loop

it faces the

rear of the chute.

Tighten the nut securely.

511 6

Inch

PAN-HEAD SCREW
(Phillips)

Inch LOCK

NUT

HOOK LOOP

inch FLAT

WASHER
