Page 43

background image

43

5. RAIL SPLITTINGS

12V1

12V2

12V3, 12V4

12V5, 12V6

1600W

1300W

SATA, HDD, FDD, 24pin

CPU1 (P4 / P8)

CPU2 (P4 / P8)

PCIe

PCIe 5�0

6. PCI-E WIRING DIAGRAM (OPTIMAL)

12V1

12V1

12V1

12V1

12V1

12V1

12V3

12V5

12V6

12V1

12V1

DRIVES

DRIVES

PCIe 5.0

PCIe 5.0

600W

600W

MB

MB

P8

P8

PCIe

PCIe

PCIe

12V3

12V4

12V4

OCK

12V2

12V2

GPUs using 1 or 2 PCIe connectors = I GPUs using >2 PCIe connectors =

Max. PCIe 5.0 Power Consumption

A

B

1600 Watt

1300 Watt

Possible OCK settings

1x 12VHPWR / PCIe 5

connector

Max� 600W

continuous power

Max� 600W

continuous power

On / Off

2x 12VHPWR / PCIe 5

connector

Max� 1000W

continuous power

Max� 800W

continuous power

On
