7. CONNECTIVITY AND CABLE LENGTHS
Overclocking jumper
Overclocking key
S-ATA
S-ATA S-ATA
S-ATA S-ATA S-ATA
S-ATA
S-ATA S-ATA
HDD
HDD
12V P8
12V P4
12V P4
PCIe 1 (6+2-pin)
PCIe 2 (6+2-pin)
PCIe 3 (6+2-pin)
PCIe 4 (6+2-pin)
PCIe 5 (6+2-pin)
PCIe 6 (6+2-pin)
HDD HDD
HDD
12V P8
20-pin
4-pin
24-pin
600mm
700mm
700mm
600mm
600mm
600mm
600mm
500mm
600mm 150mm 150mm 150mm
S-ATA
S-ATA S-ATA S-ATA
S-ATA
S-ATA S-ATA
150mm 150mm 150mm
600mm
600mm
PCIe 5.0 (12VHPWR)
PCIe 5.0 (12VHPWR)
44
Do NOT bend less than 30mm
