Page 116

5. Using On-Screen Menu

❻

Menu Descriptions & Functions [DISPLAY]

[PICTURE BY PICTURE]

Please refer to "

❷

Using a single projector to project two or four types of videos at the same time [PICTURE BY

PICTURE]" (

→

page

) for the operation.

MODE

Switch to a single-screen display, a two-screen display, or a four-screen display.

SUB1 INPUT/SUB2 INPUT/SUB3 INPUT

Select an input signal to be displayed on the sub screen.

MAIN

Two-screen display

Four-screen display

SUB1

MAIN

SUB2

SUB1

SUB3

SUB1 INPUT

Select an input signal to be displayed in the SUB 1 screen for a two-screen display or a four-
screen display.

NOTE:

• HDBaseT and SLOT are available only when [MODE] is set to [DUAL].

SUB2 INPUT

Select an input signal to be displayed in the SUB 2 screen for a four-screen display.

SUB3 INPUT

Select an input signal to be displayed in the SUB 3 screen for a four-screen display.

PORTRAIT ANGLE

Select the angle of screen orientation for a two-screen display in the portrait projection.
