Read the entire instruction manual before beginning installation. Some stock parts will
be used in reassembly.
When referencing the side of the vehicle, the driver side of the vehicle is considered the
left side and the passenger side of the vehicle is considered the right side of the vehicle.
WARNING: The 2010-2012 Camaro MT wide pedal kit (PN: L820011410) is intended
for installation in race vehicles ONLY. The width of the gas pedal is intended to better
facilitate the Heel and Toe driving technique. The close proximity of the gas and brake
pedal covers included in this kit can potentially lead to the gas pedal being inadvertently
pressed while attempting to brake.
1. For MT applications, remove the clutch
pedal rubber cover by working the rubber tabs
around the back of the pedal and pulling the
cover away from the pedal.
2. Remove the brake pedal rubber cover by
working the rubber tabs around the back of the
pedal and pulling the cover away from the pedal.
3. Line up the supplied gas pedal cover on
the gas pedal and mark the location of the four
screw holes using a silver marker, as shown in
the illustration by the silver dots. Remove the
gas pedal cover and drill a pilot hole at each
marked location using a 1/8” drill bit.
