Operate carriage control, Jt5 operator’s manual – Ditch Witch JT5 User Manual
Page 78
JT5 Operator’s Manual
Conduct a Bore - 77
Operate Carriage Control
CMW
Operate Carriage Control
The thrust/rotation control has eight positions which allow the four basic
functions to be combined. The chart below summarizes functions that occur
when control is put at a combined position. Operator must be in seat for
control to function.
Carriage Movement
Rotation Direction
forward
clockwise (makeup)
reverse
counterclockwise (breakout)
