Controls - 24
JT5 Operator’s Manual
Anchor Console
CMW
Anchor Console
1.
Left rotation control
2.
Left thrust control
3.
Right rotation control
4.
Right thrust control
Item
Description
Notes
1.
Left rotation control
To drive anchor, push down.
To remove anchor, pull up.
IMPORTANT: Stand on platform when
operating anchor controls.
