JT5 Operator’s Manual
Controls - 25
Anchor Console
CMW
2.
Left thrust control
To move anchor down, push
down.
To move anchor up, pull up.
IMPORTANT: Stand on platform when
operating anchor controls.
3.
Right rotation control
To drive anchor, push down.
To remove anchor, pull up.
IMPORTANT: Stand on platform when
operating anchor controls.
4.
Right thrust control
To move anchor down, push
down.
To move anchor up, pull up.
IMPORTANT: Stand on platform when
operating anchor controls.
Item
Description
Notes
