Oakworks Ultrasound / PG Series Rev.A - Manual (Page 12)

9
Echocardiography
electric
Fowler
electronic Lift
Towers (2)
sliding
Cardio
Panel
Adjustable
angle back
support (right
side is standard)
hand control
up
to
75
º F
owle
r angle
Paper roll
holder (1)
Locking
Casters (4)
foot control - manual cardio foot control - electric cardio
ProDUCT DeSCrIPTIon
Standard SpecificationS
Motion 1 powered 22”-38” (55.9-96.5 cm.) Height range
Motion 2 powered ±15º trendelenburg/ reverse
trendelenburg
Motion 3 powered 0-75º fowler
Hand control all powered motions
paper roll Holder accommodates up to 21” (53.3 cm.) rolls
(roll not included)
table Voltage options 120V/60Hz or 230V/50Hz
table capacity
550 lbs. (250 kg.) (patient and accessories)
Width 30” (76 cm.)
Lengths - 2 section fowler – 34” (86 cm.), Seat – 38” (97 cm.)
adjustable access/
Back Support - right Manual 4 position back support for patient
positioning
Manual Sliding cardio
panel - Left side only adjusts open up to 15” (38.1 cm.)
4” (10 cm.) Locking
casters Locking / Unlocking casters for mobile or
permanent positioning
padding 3” (8 cm.) comfort foam
™
Upholstery terra touch ™
table Weight * 359 lbs. (163 kg.)
Warranty 3 year parts, 1 year labor
Safety Listings fda, cetLus, ce marked
optionS
central Base Locking System
Sliding cardio panel - electric Upgrade (Left side only)
Side rails (2)
foot control - all powered motions
patient Lift compatible Base
acceSSorieS
detachable arm Board
t-rail adapter
QuickLock face pad
accessory Mounting plate (per end - fowler end only)
table extender - 12” (30.5 cm.) Long
For electrical specs, see specifications section.
