Directions for use – Oakworks Ultrasound / PG Series Rev.B User Manual
Page 29
26
Clamp & pole
not included.
The T-Rail Adapter can be attached at designated locations on the table, allowing the use of any
t-rail accessory. Attach or remove using the knobs shown.
NOTE: on 27” wide tables, the paper roll holder support arm must be folded down to allow
installation of the T-Rail adapter next to the paper roll holder. After installation, the paper roll
holder support arm can be raised to the normal position.
This option allows the use of patient lifts. The high clearance
base permits patient lifts to slide easily under the center of the
table for stable transfers. This option must be ordered with table.
• Includes larger, 5” diameter Heavy Duty locking Casters
• Central Base Locking System is not available with this option.
On specialty table models, there is a hand
control lock out located next to the side rail.
DIRECTIONS FOR USE
PATIENT LIFT COMPATIBLE BASE
T-RAIL ADAPTER USE
HAND CONTROL SAFETY LOCK OUT
