5
HALTECH IG5 SPECIFICATIONS
Engine Suitability
• Up to 16,000 rpm
• 1, 2, 3, 4, 5, 6, 8, 10, 12 or 16 cylinders (1-2 rotors)*
• 2 or 4 stroke
• Normally aspirated or supercharged up to 200 kPa (30 psi) – Higher boost pressure MAP sensors
available by special arrangement
• Load sensing by throttle position or manifold pressure
• Distributed ignition systems, or direct fire systems with 1 to 4 coils
Power Requirements
••••
Power Source
8.6 to 16 Volts DC
••••
Consumption
Haltech ECU: 270 mA at 12 Volts
Physical Specifications
•
ECU Dimensions
Length: 153 mm (6 1/16")
Width: 105 mm (4 1/8")
Depth: 32 mm (1 1/4")
•
Weight
ECU: 760g (1.68 lb)
Loom: 1.92kg (4.2 lb)
Sensors: 500g(1.1 lb)
Shipping Weight: 4.5kg (9.9 lb)
(Including manual/packaging)
Input Sensors
•
Manifold Absolute Pressure (MAP) Sensor, (optional at extra cost)
1 Bar -100kPa to 0kPa (Naturally Aspirated)
2 Bar -100kPa to 100kPa (up to 1 Bar or 15 psi boost)
3 Bar -100kPa to 200kPa (up to 2 Bar or 30 psi boost)
Higher boost pressure MAP sensors available by special arrangement
•
Temperature Sensors (Air and Coolant), (optional at extra cost)
NTC temperature dependent resistor type.
Operating Range
Continuous -40°C to 100°C (-40°F to 212°F)
Intermittent up to 125°C (257°F)
•
Throttle Position Sensor, (optional at extra cost)
10 k Ω rotary potentiometer driven from throttle shaft
