Hardy Bench Scales - Manual (Page 7)

Hardy Bench Scales
2-2
HIBS300 & HIBS200:
• Aluminum, environmentally potted, IP67
• Load Sensor sensitivity: 2.0 +/- 0.2 mV/V
Resolution
5000 divisions of scale capacity
Accuracy
Combined Error: 0.02%
Temperature
Operating: -10 to +40 degrees celsius
Storage: -20 to +65 degrees celsius
Warranty
Two year limited warranty
Approvals
NTEP (HIBS300 and HIBS200 Only) Pending
FM IS Hazardous Class I, Div 1 Load Cell
Shipping Weight
12" x 12": 38 lbs (17.2 kg)
18" x 18": 59 lbs (26.8 kg)
24" x 24": 104 lbs (47.2 kg)
Standard Sizes &
Capacities
