Hardy Bench Scales - Manual (Page 6)

Chapter 2 - Specifications
2-1
CHAPTER 2 - SPECIFICATIONS
Hardy Bench Scale
Specifications
Platter Construction
• 304 Stainless Steel (all models)
• Size: 12" x 12", 18" x 18" and 24" x 24

(custom sizes are available)
Deck Height
• 12" x 12": 5, 25, 50, 150 lbs: 3.75" to 4.5"
(9.5 to 11.4 cm) adjustable
• 18" x 18": 50, 25, 50, 150 lbs: 3.75" to 4.5"
(9.5 to 11.4 cm) adjustable
• 18 x 18": 300, 500 lbs: 5.5" x 6.5" (14 to 16.5
cm) adjustable
• 24" x 24": all capacities 5.5" x 6.5" (14 to
16.5 cm) adjustable
Capacity Range
5 lbs to 1000 lbs (2.27 to 454 kg)
Rated Output
Overload: 300% R.O.
End loading: 100% R.O.
Corner loading: 100% R.O.
Cable Length
Platform to Instrument - 9 to 10 feet nominal (3
meters)
(for longer cable lengths, contact the Factory)
Base Construction
HIBS400 & HIBS300: Stainless Steel
HIBS200: Painted Carbon Steel
Load Sensors
HIBS400:
• C2 ® stainless steel, hermetically sealed

IP68/IP69K
• Load Sensor Sensitivity: 2.0mV/V +/- 5%
