7
3. PRODUCT SPECIFICATIONS
Supported Video Resolution 1080p, 720p, 1080i
HDMI Interface
Supports HDMI 1.3 Video Audio format and HDCP 2.0 with
video encryption.
Transmission Distance 10 meters, in room, general line of sight (LOS)
Operating Frequencies 4.9~ 5.9GHz (with DFS function).
Antenna Omni-directional internal antennas.
Power Supply 100~ 240V AC in, 5V 3A DC out Power Adaptor
Working Temperature 0C 50C
Dimensions 71(W)*33.5(D) *16(H)mm 146(L)*93(W)*25mm(H)
4. SET-UP
4.1 Transmitter Connections
l Connect the HDMI interface of StreamEZ transmitter to any device with an HDMI output
(notebook, Blu-Ray, PS3, etc.). Use the supplied 90Degree Elbow connector if you prefer
to vertically orient the transmitter in order to create easier access to other I/O ports of the
laptop or other device.
l Connect mini-USB socket of cable to transceiver and plug cables USB interface into PC to
power transmitter. MOST laptops will require only one USB cable to be used to power
transmitter. Some laptops will require both USB cables to be plugged in, but this not
common.
l If plugging the transmitter into something other than a laptop which does not have USB
port(s) for power (such as a Blu-ray player or game console), it will require that your find a
separate USB power source OR use a USB to Wall power adapter such as the one pictured
below (not included)
