Status Reporting
32 Level 1 API
Status Reporting
Status information about the reader and the environment the reader is operating in is
available both while the reader is idle and during active background reading.
Note
Status reporting is currently only available for SerialReader type readers which
support Continuous Reading , only the M6e at this time .
StatusListener
During Continuous Reading operations it is possible to get status reports at every
frequency hop by the reader. A StatusReport object is sent to each Status listener upon
receiving the status response. A status report can contain the following information:
 Temperature - The current temperature of the reader as detected on the RF board.
 Frequency - The frequency the reader just completed using. This is the frequency the
noise floor is reported on.
 Tx and Rx port - The antenna port that the reader just completed an operation on,
which the status is associated with.

Protocol - The protocol that the reader is currently using.

RF On time - The cumulative time this port has been actively transmitting since the
reader was rebooted or this statistic was reset. (This information can be used with
total time to calculate the average transmit duty cycle since reset.)
 Noise Floor- The noise floor at the current frequency with TX on. (This information
can be used to measure changes in the amount of reflected power in the RF
environment.)
The specific status report fields returned are defined by the Reader Configuration
Parameters under /reader/status .
The desired status report fields must be explicitly selected. All default to off (false) to
minimize communications overhead.
