GROUND ORIVE
TRACTOR - - MODEL NUMBER 917.271050
KEY
NO.
1
2
PART
NO.
146682
3 123666X
4 12000028
5 121520X
6 17060512
8 165866
10 STD561210
11 105701X
13 74550412
14 10040400
16 STD541431
18 STD523710
19 STD541437
21 106933X
22 130804
24 STD541237
25 106888X
26 STD551037
27 STD561210
28 145204
29 71673
30 169592
32 STD523107
34 155071
35 120183X
36 STD551062
37 STD571810
38 131494
39 STD533727
40 4470J
41 165838
42 19131312
47 127783
48 154407
49 123205X
50 STD523715
51 STD541437
52 STD541431
53 105710X
55 105709X
56 STD523712
57 130801
59 169691
61 17060612
62 8883R
63 140186
DESCRIPTION
Transaxle (See Breakdown)
Peerless 206-545C
Spring, Return, Brake
Pulley. Transaxle
Ring, Retainer
Strap. Torque
Screw 5/16-18x3/4
Rod Shifter Fender STLT
Pin, Cotter
Washer, Shift Plate
Bolt 1/4-28 UNF W/Patch Gr. 8
Washer Lock Hvy Heiical
Nut Lock Hx W/lns
5/16-18 xGr.5
Bolt Fin Hex
3/8-16UNCX1 Gr.5
Nut
Knob
Rod, Brake
Nut
Spring, Brake Rod
Washer
Pin
Rod, Parking Brake
Cap, Parking Brake
Bracket, Transaxle
Bolt
Shaft Assembly, Foot Pedal
Bearing, Nylon
Washer
Roll Pin
Pulley, Idler, Flat
Bolt
Spacer, Split .395 x .59
Keeper, Belt, Idler
Washer 13/32 x 13/16 x 12Ga.
Pulley, Idler, V-Groove, Plastic
Bellcrank Clutch Gmd Drv St!
Retainer, Belt
Bolt
Nut Crown Lock 3/8-16 UNC
Nut Crown Lock 5/16-18 UNC
Link, Clutch
Spring, Clutch Return
Bolt Fin Hex 3/8-16 X 1-1/4
V-Belt, Ground Drive
Keeper, Belt, Center Span
Screw 3/8-16x3/4
Cover, Pedal
Pulley, Engine
KEY PART
NO. NO. DESCRIPTION
64 71170764 Bolt, Hex 7/16-20 X 4 Grade 5
65 STD551143 Washer
66 154778 Keeper, Belt, Engine, Fool
Proof
Guide, Mower Drive Belt, R.H.
70 134683
72 19132012 Washer 13/32 x 1-1/4 x 12 Ga.
74 137057 Spacer, Axle .
75 121749X Washer 25/32 x 1-1/4 x 16 Ga.
76 STD581075 E-Ring
77 123583X Key, Square 2.0 x .1845/1865
78 121748X Washer 25/32 x 1-5/8 x 16 Ga
79 STD580025 Key Woodruff
80 145090 Arm, Shift
81 165592 Shaft Asm Cross Tapered
65020
Spring, Torsion 82 165711
83 19171216 Washer 17/32 x 3/4 x 16 Ga.
84 166231 Link Transaxle
85 150360 Nut, Nylock
89 158391X428 Console. Shift, STLT
90 124346X Nut, Self-Thding, Wsh Hd 1/4
96 STD624003 Retainer Spring 1"
112 19091210 Washer 9/32 x 3/4 x 10 Ga.
113 127285X Strap Torque 90 Degrees
116 72110610 Bolt Rdhd Sqneck
3/8-16 X 1.25
145 74490540 Bolt, Hex FIghd 5/16-18 Gr. 5
150 165850 Bushing Bellcrank Grd. Drive
151 19133210 Washer 13/32 x 2 x 10 Ga.
156 166002 Washer Srrted 5/l6IDx 1.125
158 165589 Bracket Shift Mount
159 165494 Hub Tapered Flange Shift Lt
161 72140406 Bolt Rdhd Sqnk 1/4-20 x 3/4
Gr.5
162 73680400 Nut Crownlock 1/4-20 Unc
163 74780416 Bolt Hex Fin
1/4-20Unc X 1 Gr 5
164 19091010 Washer 5/8 x .281 x 10 Ga
165 165623 Bracket Pivot Lever
166 166880 Screw 5/16-18x5/8
168 165492 Bolt Shoulder 5/16-18 x .561
169 165580 Plate Fastening Lt
170 165849 Keeper Belt Transaxle Gear.
197 169613 Nyliner Snap-In
198 169593 Washer Nyliner
202 72110612 Bolt Carr. SH
3/8-16x1-1/2 Gr.5
204 17060516 Screw 5/16-18 X1 SMGML
