SEARS CRAFTSMAN 18" ELECTRIC ROTARY MOWER MODEL NO. 247.370320
Repair Parts
KEY
NO.
PART
NO.
DESCRIPTION
KEY
NO.
PART
NO.
DESCRIPTION
101 731-1210 Handle—Switch 125 741-0572 Bearing—Spherical
102 731-1208 Housing—Upper Half 126 724-0189 Armature Shaft
103 732-0679 Spring 127 721-0264 “0”-Ring
104 731-1198 Latch 128 721-0267 “0”-Ring
105 725-1565 Switch 129 741-0573 Bearing—Upper Flange
106 731-1209 Housing—Lower Half 130 736-0460 Thrust Washer (Special)
107 732-0681 Latch Spring 131 717-1345 Gear Output
108 629-0023 Cord Assembly 132 731-1216 Insulator—Motor Housing
109 729-0304 2-Prong Plug 133 726-0302 Wire Tie
111 731-1207 Strain Relief—Heyco 135 721-0272 Seal
112 741-0537 Bearing—Lower Flange 137 710-1147 Screw—Switch Box
113 719-0286 Motor Housing—L.H. (Special—Not Shown)
114 818-60004 Brush Assembly 139 731-1211 Plug Retainer
115 818-60002 Jumper Wire Ass’y. 140 629-0004 Cord & Switch Box Ass’y-
116 735-0242 Pad—Pressure (Complete)
117 818-60007 Field Assembly 148 719-0287 Motor Housing—R.H.
119 724-0159 Spring—Field 152 711-0902 Shaft Output
120 710-1146 Screw #10-24 x 1-1/8" Special 158 818-60011 Motor & Switch Assembly
123 721-0265 Wick—Oil (Complete)
124 721-0266 “0”-Ring
‘Not Part of Complete Motor & Switch Assembly.
A
WARNING: The motor is an important
part of the double insulated system. To
avoid the possibility of aiteration or
damage to the system, it is recom­
mended that service be performed at a
Sears Service Center.
18
