SEARS CRAFTSMAN 18" ELECTRIC ROTARY MOWER MODEL NO. 247.370320
Repair Parts
KEY
NO.
PART
NO.
DESCRIPTION
KEY
NO.
PART
NO.
DESCRIPTION
1
710-0255
Truss Mach. Scr. V4-20 x .75"
13
710-0969
Truss Mach. Hi-Riser Tap Scr.
Lg-
#12
X
1" Lg.
2
736-0329
L-Wash. 1/4" I.D.*
14
736-0105
Bell-Wash. .38" I.D. x .88"
3
720-0236
Plastic Knob
15
738-0102
ShId. Bolt .498" Dia. x 1.45"
4
732-0675
Ball Plunger
16
734-1670
Front Wheel Ass’y- Comp.
5
738-0137
Shid. Bolt .342" Dia. x .268" Lg.
17
731-0981A
Hub Cap
6
738-0811
Height Adjuster Spindle
18
17802
Height Adj. Spindle Brkt.
7
731-1128
Spindle Guide
19
710-0969
Truss Mach. Hi-Riser Tap Scr.
8
747-0589
Height Adjustment Rod
#12
X
1" Lg.
9
747-0802
Height Adjustment Link
21
741-0180
Ball Bearing
10
714-0104
Int. Cotter Pin 5/16" Dia.
22
736-0232
Wave Wash. .53" I.D.
11
17521
Front Axle Ass’y.
23
736-0326
FI-Wash. .51" I.D. x 1" O.D.
12
17800
Axle Mounting Plate
16
