SEARS CRAFTSMAN 18" ELECTRIC ROTARY MOWER MODEL NO. 247.370320
Repair Parts
KEY
NO.
PART
NO.
DESCRIPTION
KEY
NO.
PART
NO.
DESCRIPTION
1 750-0289 Spacer .508" I.D. x .875" O.D. 55 731-1106 Chute Door
2 748-0343 Blade Adapter 57 731-1101 Deck Ass’y.
3 710-1006 Hex Wash. Hd. TT-Tap Scr. 58 736-0461 FI-Wash. 5/16" I.D. x .75" O.D.
3/8-16 X .75" Lg. 59 712-0429 Hex L-Nut 5/16-18 Thd.
4 712-0296 Hex L-Nut 3/8-24 Thd. 60 731-1257 Motor Shield
5 732-0478 Extension Spring 6.12" Lg. 61 731-1255 Insulator Spacer
6 710-1220 Truss Mach. Hi-Riser Tap Scr. 68 712-0400 U-Nut #10-16 Thd.
#12 X .75" Lg. 69 710-0351 Truss Mach. B-Tap Scr.
8 731-1218 Blade Adapter Insulator #10 X .5" Lg.
9 731-1217 Blade Insulator 70 710-0969 Truss Mach. Hi-Riser Tap Scr.
10 710-0451 Carriage Bolt 5/16-18 x .75" Lg. #12 X 1" Lg.
11 750-0812 Pivot Spacer—-R.H. 71 17740 Spiral Baffle
12 750-0813 Pivot Spacer—L.H. 72 731-1109 Chute Baffle
13 712-0437 Hex Keps Nut 5/16-18 Thd. 74 731-1113 Hardtop Cover Plate
14 736-0462 FI-Wash. .516" I.D. x 1.5" Lg. 75 731-1108 Hardtop Cover
15 712-0401 Slotted Hex Nut 1/2-20 Thd. 76 720-0272 Magnetic Catch
16 714-0228 Cotter Pin 1" Lg. 77 747-0538 Catcher Frame
17 742-0576 18" Blade 78 17801 Bag Frame Mtg. Plate
18 725-1590 Cord Restraint 79 764-0273 Grass Bag
19 625-0004 Cord and Switch Ass’y- 83 736-0242 Bell-Wash. 5/16" I.D. x .88"
(Complete) 84 818-60006 Plate Ass’y.
20 710-1150 Self-Tap Scr. # 7 x 1 " L g . 8 5 731-1216 Insulator—Motor Housing
21 710-1128 Pan Hd. Scr. #10-16 X .75" Lg. 86 736-3090 FI-Wash. .26" I.D. x .72" O.D.
31 712-0346 Hex L-Nut 1/2-20 Thd. 87 712-0324 Hex Top L-Nut V4-20 Thd.
. 32 720-0226 Foam Grip 88 731-1256 Motor Cover
33 726-0308 Clamp 89 726-0306 Cable Tie
34 17803 Rear Axle Ass’y- 90 710-0280 Truss Mach. Scr. #10-24 x .75"
36 750-0151 Spacer .55" I.D. x .755" O.D. Lg-
37 720-0241 Knob Ass’y. 91 712-0410 Clip
38 736-0451 Saddle Washer .32" I.D. 99 734-1513B Wheel Ass’y. Comp.
39 710-1152 Curved Carr. Bolt 5/16-18 x 2" 101 726-0287 Clamp
Lg-
102 731-0898 Rear Flap
40 818-60011 Motor & Switch Ass’y. 105 731-0981A Hub Cap
41 749-0832 Lower Handle 106 741-0180 Ball Brg. Vz" I.D.
42 749-0849 Upper Handle 109 710-1131 Truss Hd. Scr. V4-20 x 2" Lg.
47 710-0874 Hex Bolt 5/16-18 X 1.25" Lg. 110 750-0816 Spacer .26" I.D. x 1.20"
48 732-0646 Handle Latch Spring—R.H. Lg.—R.H.
732-0647 Handle Latch Spring—L.H. 750-0817 Spacer .26" I.D. x 1.52"
49 17748 Handle Lock—R.H. Lg.—L.H. (Not Shown)
50 17749 Handle Lock—L.H. 111 738-0839 Latch Plate Bushing
51 726-0211 U-Nut 5/16-18 Thd. 112 750-0503 Spacer .383" I.D. x .562" Lg.
52 732-0654 Torsion Spring—R.H. 113 712-0399 Propel Nut V4-20 Thd.
53 732-0653 Torsion Spring—L.H. 115 731-1112 Rear Discharge Chute Deflector
54 747-0773 Hinge Pin 14.5" Lg.
'Common Hardware—May Be Purchased Locally.
NOTE: Specifications subject to change without notice or obligation.
