CRAFTSMAN 5 H.P. ENGINE MODEL NO. 143.955000
Repair Parts
RPM Setting:
Low Speed: 2750-3050
High Speed: 3200-3400
KEY
NO.
PART
NO.
DESORIPDON
KEY
NO.
PART
NO.
DESCRIPTION
1 36478A Cylinder (Incl. 2 , 7,20 & 125) 172 32755 Valve Cover
2
26727 Dowel Pin 174 30200 Screw, 10-24x9/16"
6 33734 Breather Element 178 29752 Nut & Lock Washer, 1/4-28
7 36557 Breather Body Ass’y- (Incl. 6 & 12) 182 6201 Screw. 1/4.28 X 7/8"
12 36558 Breather Covers Tube (Inci. 12B) 184 2S756 Carburetor to Intake Pipe Gasket
12B 34695 Breather Tube Elbow 185 31384A Intake Pipe (Incl. 224)
14 28277 Washer 186 34358 Governor Link
15 30589 Governor Rod (Incl, 14) 189 650839 Screw, 1/4-20 X 3/8"
16 31383A Governor Lever 191 36559 S.E, Brake Bracket (Incl. 195)
17 31335 Governor Lever Clamp 195 610973 Terminal
18 650548 Screw, 8-32x5/16" 200 35727 Control Bracket (Incl. 202 thru
19 36281 Extension Spring 205}
20 32600 Oi! Seal 202 36482 Compression Spring
30 36215 Crankshaft 203 31342 Compression Spring
40 36073 Piston, Pin S Ring Set (Std.)
Piston. Pin & Ring Set (.010" OS)
204 650549 Screw. 5.40x7/16"
40 36074 205 650777 Screw, 8-32 X 21/32"
40 36075 Piston, Pin S Ring Set (.020" OS) 207 34336 Throttle Link
41 36070 Piston & Pin Ass'y- (Std.) (Inci. 43) 209 30200 Screw, 10-24 x 9/16"
41 36071 Piston & Pin Ass'y- {.010“ OS) 215 35511 Control Knob
(Incl. 43) 223 650451 Screw, 1/4-20 X 1"
41 36072 Piston & Pin Ass’y. (.020" OS) 224 34690A Intake Pipe Gasket
(Incl. 43) 238 650932 Screw, 10-32 X 49/64"
42 36076 Ring Set (Std.) 239 34338 Air Cleaner Gasket
42 36077 Ring Sat (.010" OS) 241 35797 Air Cleaner Collar
42 36078 Ring Set (.020" OS) 245 35066 Air Cleaner Fitter
43 20381 Piston Pin Retaining Ring 250 35065 Air Cleaner Cover
45 30963B Connecting Rod Ass'y. (Incl, 46) 260 35826 Blower Housing
46 3261OA Connecting Rod Bolt 261 30200 Screw. 10-24 X 9/16"
46 27241 Valve Lifter 262 650831 Screw, 1/4-20 X 1/2"
50 35992 Camshaft (MGR) 263A 35821 Starter Grill
62 29914 Oil Pump Ass’y. 275
36473 Muffler (Ind. 277)
69 35261 Mounting Flange Gasket 277 650988 Screw, 1/4-20 x 2-5/16"
70 34311D Mounting Flange (Incl. 72 thru 83) 285 35000A Starter Cup
72 36083 Oil Drain Plug 287 650926 Screw, 8-32 X 21/64"
75 27897 Oil Seal 290 34357 Fuel Line
80 30S74A Governor Shaft 292 26460 Fuel Line Clamp
81 30S90A Washer 300 35586 Fuel Tank (Incl. 292 & 301)
82 30591 Governor Gear Ass’y. (Inci. 81) 301 35355 Fuel Cap
63 30588A Governor Spool 305 35819A Oil Fill Tube
86 650488 Screw, 1/4-20 X 1-1/4" 306 34265 “0"-Ring
89 611004 Flywheel Key 307 35499 "0".Ring
90 611112 Flywheel 309 650936 Screw, 10-32 X13/32"
92 650815 Belleville Washer 310 35822 Dipstick
93 650816 Flywheel Nut 313 34080 Spacer
100 34443A Solid State Ignition 347 650698 Screw, 10-32 X 27/64"
101 810118 Spark Plug Cover 370A 36261 Lubrication Decal
103 650814 Screw, Tor> T-15,10-24 x 1" 370B 35167 Control Decal
110 34961 Ground Wire 370D 35977 Caution Decal
119 36477 Cylinder Head Gasket 380 632670 Carburetor (Incl. 184)
120 36476 Cylinder Head 390 590702 Recoil Starter
125 36471 Exhaust Valve (Std.) (Incl. 151) (NOTE: This engine could have been built with
125 36472 Exhaust Valve (1/32" OS)
590637 starter. Refer to the design of the air
126
126
130
135
150
29314B
29315C
6021A
35395
35991
(Incl. 151)
Intake Valve (Std.) (Incl. 151)
Intake Valve (1/32" OS) (Incl. 151}
Screw, 5/16-18 X 1-1/2"
Resistor Spark Plug (RJ19LM)
Valve Spring
400
intake louvers
starter parts dc
36481
for part identification. Individual
not interchange.)
Gasket Set (incl. Part Nos. 26756,
27234A, 33735, 34265, 34338,
34690A, 35261, 36477
151 31673 Valve Spring Cap
416 36085 Spark Arrestor Kit (incl. 417)
166 35827 Engine Shroud
417 650760
(Optional)
169 27234A Valve Cover Gasket Screw, 8-32 X 3/8" (Optional)
21
