SEARS CRAFTSMAN 21"
Repair Parts
MULCHING ROTARY MOWER MODEL NO. 247.372900
KEY
NO.
PART
NO.
DESCRIPTION
KEY
NO.
PART
NO.
DESCRIPTION
1 720-0225 Grip (2 Req’d.) 62 782-7563 Bracket—Shift Plata
2
747-0824 Control Handle 63 736-0451 Saddle Washer ,32" I.D.
3 710-1205 Rope Guide 64 682-3006A R.H. Handle Wheel Brki. Ass’y.
4
712-0279 Wing Nut 1/4-20 Thd. 65 682-3007A L.H. Handle Wheel Brkt. Ass'y.
5 750-0968 Spacer .885" I.D. 66 710-0260 Carriage Bolt S/16-18 x .62"*
6 747-0855 Belt Guard 67 710-0603 Hex B-Tap Scr. 5/16-18
7 736-0329 L-Wash. ■1/4" I.D.* 68 710-0654A Hex TT-Tap Scr. 3/8-16
8 712-0287 Hex Nut 1/4-20 Thd.* 69 712-0267 Hex Nut 5/16-18 Thd.*
9
736-0526 Wave Wash. .88" I.D. x 1,38" 70 720-0230 Grip
O.D. 71 732-0725 Height Adj. Lever
10 782-7007 Grass Catcher Bracket 73 736-0242 Bell-Wash.5/16" I.D.
11 731-0981A Hub Cap 74 750-0738 Spacer.383" I.D.
12 710-1270 Oval C-Sunk Mach. Scr. 75 750-0624 Shid. Spacer .5" Dia.
13 746-0883 Throttle Body 77 712-0291 Hex L-Nut 1/4-20 Thd.
14 749-0539B Upper Handle 79 710-0653 Hex Wash. Hd. Tap Scr, 1/4-20
16 731-1409 Side Chute Deflector X .38" Lg.
17 731-1501 Mulch Plug 80 738-0137 ShId. Scr, .342" Dia. x .268
18 714-0104 Internal Cotter Pin 5/l6" Dia. 81 748-0381 Pawl—R.H.
20 747-0710 Hinge Pin 748-0188B Pawl
21 782-7006 Plug Adapter 82 734-151 OB Wheel Ass'y, Comp.—Rear
22 732-0731 Torsion Spring 84 741-04868 Sleeve Bearing i/2" i . d .
23 682-7002 Mulch Plug Ass'y- Comp, 86 712-0414 Weld Top L-Nut 1/4-20 Thd.
(Incl. Ref, 17, 20, 21,22) 95 746-071OA S.P. Cable
24 736-0270 Beil-Wash. .265" I.D. x ,75" O.D.96 754-0343 "V"-Bett
2S 710-0167 Carriage Bolt 1/4-20 x .5" Lg. 98 711-0313 Sleeve ,526" I.D.
26 17070 Adjustable Cable Bracket 99
710-1055 Hex Bolt 3/8-24 X 1.0" Lg.
27 1685S Pawl Plate
100
712-0241 Hex Nut 3/8-24 Thd.
28 782-7009 Chute Stop Bracket
101 736-0169 L-Wash. 3/8" I.D.
29 712-0324 Hex L-Nut 1/4-20 Thd. 102 732-0027 21" Deck Ass’y.
30 714-0507 Cotter Pin 3/32" Dia. x .75" 114 731-0904 Upper Control Housing
31 736-0278 Fl-Wash. .328" I.D. X .68" 115 731-0905 Lower Control Housing
32 735-0639 Spark Plug Insulator 118 710-0841 Fi-"C"-Sunk Hd. Tap Scr, #10
X
33 656-0612 Lower Pulley Half Ass’y. .75" Lg.
34 747-0382A Shift Rod 119 731-0620 Control Lever
35 749-0928 Lower Handle
121
710-1174 Curved Hd. Bolt 5/16-18 x 2" Lg.
36 143.955000 Engine—Craftsman Model
122 711-0805 Shid. Pin 1.43" Lg,
143.955000 128 712-0711 Hex Jam Nut 3/8-24 Thd.*
37 582-7514 Housing,Ass’y.
129
746-0737 Control Cable—51"
38 731-1137 Flanged Bushing 130 748-0318 Ratchet Wheel 1.62" O.D.
40 746-0706 6-Spd. Cable 131 714-0115 Cotter Pin 1/8" Dia. X 1"*
42 682-7513 Chain—/ofle Ass'y. 134 741-0522 Hex Flange Bearing
43 710-0653 Hex Hd. Tap Scr. 1/4-20 x ,38" 136 10822B Spring—Nylon
Lg. 138 682-7506 Chain Cover Ass’y.
44 736-0270 BelWash. 1/4" I.D. 140 710-0599 Hex TT-Tap Scr. 1/4-20 X .50"
45 710-0351 Truss Mach. B-Tap Scr, #10 x ,5" 147 738-0864 Rear Shaft Ass'y. 21.44" Lg.
47 712-0296 Hex Patch L-Nut 3/8-24 Thd. 148 741-0324 Hex Flange Brg. ,506" I.D,
46 713-0361 #48 Chain .500" Pitch x 38
149
736-0160 Fl-Wash. .531" I.D. x .930"
Links 152 710-0751 Hex Bolt 1/4-20 x .62" Lg.
49 720-0241 Hand Knob (Grade 5)
50 731-0906 Cable Mounting Cap 153 618-0055 Transmission Comp.
51 731-1483 Rear Flap 4.8" x 17.5" Lg. (See Breakdown)
52 726-0240 Cable Tie 154 16500A Hex Bearing Cup
55 748-0367 Blade Adapter 155 736-0300 Fl-Wash. .385" I.D. X .87" O.D,
56 742-0721 21" Mulching Blade 163 713-0397 Gear Insert
58 736-0452 Bell-Wash, ,39" I.D. X 1.14" 165 731-0924 6-Spd. Shift Lever
O.D. 177 732-0627 Shift Lever Spring
so 710-1257 Hex Bolt 3/8-24 X 2.5" Lg. 178 16864 6-Spd. Rack Cable Brkt.
31 748-0190 Spacer ,513" I.D.
,-----
770-8875K Owner's Manual
‘Common Hardware—May Be F’urchased Locally.
NOTE: Specifications subject to change without notice
or obligation,
