CUSTOMER RESPONSIBILITIES
• To check blade balance, drive a nail into a beam or
wall. Leave about one inch of the straight nail
exposed. Place center hole of blade over the head
of the nail. If blade is balanced, it should remain in
a horizontal position. If either end of the blade
moves downward, blade is not balanced. Sharpen
the heavy end until the blade Ls balanced.
ENGINE
ENGINE LUBRICATION
You must change the oil in the crankcase after the
first two (2) hours of operation and after each 25
hours of use thereafter. CHANGE THE OIL MORE
FREQUENTLY IF USED IN SANDY OR DUSTY
CONDITIONS.
TO DRAIN OIL
• Disconnect spark plug wire from spark plug and
place wire where it cannot come in contact with plug.
• Drain the gas tank,
• Remove the oil fill cap and dipstick. Turn and tip
the unit on Its side with the carburetor up, and drain
oil into a suitable container.
• Refill crankcase with oil. Refer to “ENGINE OIL
RECOMMENDATIONS" on previous page.
• Replace oil fill cap and dipstick. Tighten cap
securely.
SPARK PLUG
Change your spark plug each year to make your
engine start easier and run better. Set spark plug gap
at ,030 inch.
AIR FILTER
Your engine will not run properly and may be dam­
aged by using a dirty air filter.
Replace the air filter every year, iTiore often if you mow
in very dusty, dirty conditions. Do not wash air filter.
TO CHANGE AIR FILTER {See Figure 10):
• Remove the air filter cover by turning counterclock­
wise to the stop and pull away from collar.
• Remove filter from inside of cover,
* Clean the inside of the cover and the collar with a
clean Cloth to remove any dirt accumulation.
• Insert new filter into cover.
• Put air filter cover and filter into collar aligning the
tab with the slot.
* Push in on cover and turn clockwise to tighten.
Collar
Air Filter
FIGURE 10.
CLEANING
Turn
Counter-
Clockwise
To Remove
Turn Clockwise
/ To Tighten
Air Filter Cover
A
WARNING: DISCONNECT SPARK PLUG
WIRE FROM SPARK PLUG AND PLACE
WIRE WHERE IT CANNOT COME IN CON­
TACT WITH THE SPARK PLUG.
• Turn mower on its side with carburetor and air filter
up.
• Clean the underside of your mower after each use
by scraping to remove build-up of grass clippings,
leaves, dirt or other matter. If this debris is allowed
to accumulate, it will invite rust and corrosion, and
may prevent proper mulching.
• Clean your mower and engine often to keep build­
up of grass or debris from accumulating around
engine. A clogged engine runs hotter and shortens
engine life.
NOTE: We DO NOT recommend using a garden hose
to clean mower unless the electrical system, muffler,
air filter and carburetor are covered to keep water out.
Water in engine can result in shortening engine life.
SERVICE AND ADJUSTMENT
CUTTING HEIGHT ADJUSTMENT
Refer to “ADJUST CUTTING HEIGHT" In operation
section of manual,
HANDLE HEIGHT ADJUSTMENT
Your mower is shipped with the handle in the higher
height position. To lower the handle height, proceed
as follows.
• Remove the starter rope from the rope guide.
• Remove the upper handle by removing the hand
knobs and carriage bolts. Lay the upper handle out
of the way, being careful not to bend or kink the
cable.
• Remove the hairpin clips from the weld pins on the
handle brackets. Press outward on the sides of the
lower handle, and remove it from the mower.
