Craftsman 247.298760 - Manual (Page 21)

Repair Parts 8-H.P. Tiller Model 247.298760
REF.
NO.
PART 1
NO.
DESCRIPTION
REF.
NO.
PART
NO.
DESCRIPTION
1 . ^52-0663 Engine Tecumseh Model 28 04898 Belt Guard Support—Rear
HM80-15162E 29 715-0124 Spring Pin Spiral 5/32 Dia. x
2 710-0599 Thread Rolling Scr. V4-20 x .62” Lg.
.50” Lg. 30 10844 Sheave Half
3 04899 Belt Cover 31 741-0139 Ball Bearing
4 04896 Front Belt Guard Support 32 750-0146 Spacer
Ass’y. 33 04893 Idler Arm Ass’y.
5 736-0114 Internal L-Wash. V 2 ” Dia. 34 747-0271 Control Rod 3/8” Rod *
6 710-0121 Hex Scr. V 2-20 X .15 Special 35 738-0140 Shid. Bolt .437 Dia. x .180
7 717-0390 Variable Speed Pulley Ass’y- 36 711-0494 Spacer .510 I.D. x .760 O.D.
8 736-0142 FI-Wash. .281 I.D. x .50O.D. X .390” Lg.
X .63 37 710-0515 Hex Scr. V
2
-
2
O X 3.50” Lg.
9 756-0313 Idler Pulley 38 714-0115 Cotter Pin 1/8” Dia.*
10 712-0262 Hex Jam Nut 3/8-24 Thd. 39 04889 Pivot Arm Ass’y.
11 756-0305 Pulley 4.50” Dia. 40 714-0145 Internal Cotter Pin V
2
” Dia.
12 736-0231 FI-Wash. 5/16” I.D. x 1.120” 41 711-0599 Clevis Pin
O.D. 42 742-0175 Tine—L.H.
13 736-0119 L-Wash. 5/16” Scr.* 43 742-0174 Tine—R.H.
14 710-0573 Hex Scr. 5/16-18 x 1.25” Lg.* 44 06797 Outer Tine Adapter Ass’y.
15 710-0230 Hex Scr. V4-28 x .50” Lg.* 45 04695 Outer Tine Ass’y. Comp.—
16 754-0231 “V”-Belt V 2 ” X 28” Lg. L.H.
17 754-0232 ”V”-Belt V 2 ” X 20” Lg. 46 712-0241 Hex Nut 3/8-24 Thd.*
18 712-0239 L-Nut V 2 - 2 O Thd. 47 736-0169 L-Wash. 3/8” Scr.*
19 04900 Friction Wheel Ass’y. 48 710-0191 Hex Scr. 3/8-24 x 1.25” Lg.*
20 710-0191 Hex Scr. 3/8-24 x 1.25” Lg.* 49 06821 Inner Tine Ass’y. Comp.—
21 736-0169 L-Wash. 3/8” Scr.* L.H.
1 22 736-0258 FI-Wash. 3/8” I.D. x 1.00” 50 06798 Inner Tine Adapter Ass’y.
O.D. 51 712-0267 Hex Nut 5/16-18 Thd.*
23 756-0306 Engine Pulley 52 736-0170 Shakeproof Washer
24 714-0133 Sq. Key 3/16 x 1.50” Lg. 53 06822 Inner Tine Ass’y. Comp.—
25 750-0229 Spacer .635” I.D. x .88 O.D. x R.H.
1.035” Lg. 54 04696 Outer Tine Ass’y. Comp.—
26 732-0376 Extension Spring R.H.
27 710-0599 Hex Tapp Scr. V4-20 x .50” 55 04776 Tine Shield
Lg. 56 710-0442 Hex Scr. 5/16-18 x 1.50” Lg.*
•Standard Hardware Items—May Be Purchased Locally.
TILLER ACCESSORIES
Til-Row Attachment 8” Furrower
Leveling/Snow-Blade Kit 15” Sweep Cult./Hoe
V-Bar Cultivating Kit 32” Leveling Rake
Drag Stake Cultivating Kit Cultivating Shields
32” Leveling/Snow-Blade V-Bar Frame
4-pt. Cultivator Tines
13 X 5.00—6 Pneumatic Traction Tires
Hiller/Furrower Wheel Weights
Depth Gauge Wheels Tire Chains (Pr.)
6-Tang Universal Cult.
Drag Stake
Wheel Weights F/Leveling Snow-Blade
THESE ACCESSORIES ARE AVAILABLE IN THE
SEARS BIG SPRING CATALOG..
