PARTS LIST
Engine — Model No. 247.28672
Ref. No. Part No. Description
750 796208 Screw (Oil Pump Cover)
783 695708 Gear-Pinion
789 797424 Harness-Wiring
798 697890 Screw (Rocker Arm)
801 691283 Cap-Drive
802 691286 Cap-End
803
Housing-Starter (Service with Starter
Motor 499521, Reference 309)
842 691031 Seal-0 Ring (Dipstick Tube)
847 499602 Dipstick/Tube Assembly
850 100106 Sealant-Liquid
851 493880s Terminal-Spark Plug
865 792286 Cover-Air Guide (Valley)
868 + 690968 Seal-Valve
883 + & 690970 Gasket-Exhaust
914 691127 Screw (Rocker Cover)
918 797408 Hose-Vacuum
929 695239 Screw (Choke Control Bracket)
943 796222 Seal-0 Ring (Oil Pump Cover)
947 841546 Solenoid-Fuel
965 796221 Cover-Oil Pump
967 792303 Filter-Pre Cleaner
968 795120 Cover-Air Cleaner
975 793592 Bowl-Float
987 691000 Seal-Throttle Shaft
1005 791236 Fan-Flywheel
1013 690954 Nipple-Oil Filter
1017 796214 Screen-Oil Pump
1022 690971 Gasket-Rocker Cover
1023 793146 Cover-Rocker (Cylinder #1)
1023A 499600 Cover-Rocker (Cylinder #2)
1024 796220 Pump-Oil
1026 690981 Rod-Push (Exhaust)
1026A 690982 Rod-Push (Intake)
1027 795890 Filter-Oil
1029 690972 Arm-Rocker
1036
Label-Emissions (Available from a
Briggs & Stratton Authorized Dealer)
1040 791237 Plate-Trim
Ref. No. Part No. Description
1051 691265 Ring-Retaining (Starter Drive)
1054 280275 Tie-Cable
1058 277103 Operator's Manual
1059 698516 Kit-Screw/Washer (Alternator)
1070 791680 Screw (Flywheel Fan)
1090 691293 Retainer-Brush
1095 694013 Gasket Set-Valve
1100 791959 Pivot-Rocker Arm
1119 691183 Screw (Alternator)
1124 841653 Seal-0 Ring (Fuel Transfer Tube)
1124 A 690988 Seal-0 Ring (Fuel Transfer Tube)
1126 690991 Screw (Fuel Transfer Tube)
1127 695407 Screw (Fuel Bowl)
1128 690990 Screw (Carburetor Nozzle)
1169 690990 Screw (Carburetor Plate)
1330 273521 Repair Manual
1329 BS-44Q777-0137-G1 Replacement Engine
+ — Included in Engine Gasket Set, Key. No. 358
& — Included in Valve Gasket Set, Key No. 1095
% — Included in Carburetor Overhaul Kit, Key No. 121
56
