PARTS LIS
I J
Engine — Model No. 247.28672
Ref. No. Part No. Description
219 793338 Gear-Governor
220 690412 Washer (Governor Gear)
221 841026 Cup-Governor
222 796226 Bracket-Control
227 796223 Lever-Governor Control
231 690718 Screw (Choke Valve)
240 695666 Filter-Fuel
250 690957 Retainer-Breather
252 794389 Collector-Oil
265 691024 Clamp-Casing
267 695134 Screw (Casing Clamp)
276 % 695410 Washer-Sealing
278 792651 Washer (Governor Control Lever)
287 697551 Screw (Dipstick Tube)
304 797407 Housing-Blower
305 691005 Screw (Blower Housing)
305A 790690
Screw (Blower Housing to Intake
Elbow)
306 796541 Shield-Cylinder (Cylinder #2)
306A 796852 Shield-Cylinder (Cylinder #1)
307 697551 Screw (Cylinder Shield)
309 499521 Motor-Starter
310 691263 Screw (Starter Motor)
332 691059 Nut (Flywheel)
333 691060 Armature-Magneto
334 691061 Screw (Magneto Armature)
337 491055s Plug-Spark
358 694012 Gasket Set-Engine
385 797409 Screw (Fuel Pump)
387 808656 Pump-Fuel
404 690442 Washer (Governor Crank)
415 794903 Plug (Oil Pressure Switch Hole)
418 795912 Plate-Carburetor
431 792297 El bow-Intake
445 792105 Filter-Air Cleaner Cartridge
447 691003 Screw (Air Guide Cover)
467 790697 Knob-Air Cleaner
474 696458 Alternator
501 797375 Regulator
Ref. No. Part No. Description
503 691532 Strap-Starter
505 691029 Nut (Governor Control Lever)
510 696541 Drive-Starter
512 796530 Hose-Oil Drain
513 692024 Clutch-Drive
523 691036 Dipstick
524 + 691032 Seal-Dipstick Tube
525 691037 Tube-Dipstick
526 697551 Screw (Regulator)
544
Armature-Starter (Service with Starter
Motor 499521, Reference 309)
552 796638 Bushing-Governor Crank
552A 690553 Bushing-Governor Crank
562 690311 Screw (Governor Control Lever)
573 790444 Plate-Back
579 691029 Nut (Starter Cable)
601 691038 Clamp-Hose (Black)
615 698290 Retainer-Governor Shaft
616 691045 Crank-Governor
617 697891 Seal-0 Ring (Intake Manifold) (Red)
633 % 699813 Seal-Choke/Throttle Shaft
634 698779 Spring/Seal Assembly
635 66538s Boot-Spark Plug
654 690958 Nut (Carburetor)
668 + 691215 Spacer (Rotating Screen)
668A 691500 Spacer (Rotating Screen)
672 690234 Gasket-Carburetor Plate
691 + 790574 Seal-Governor Shaft
695 693149 Screw (Ring Gear)
697 690372 Screw (Drive Cap)
703 691010 Clip
718 690959 Pin-Locating
726 499612 Gear-Ring
729 797454 Clip-Wire
741 690980 Gear-Timing
742 690328 Retainer-E Ring (Governor Crank)
+ — Included in Engine Gasket Set, Key. No. 358
& — Included in Valve Gasket Set, Key No. 1095
% — Included in Carburetor Overhaul Kit, Key No. 121
