PARTS LIS
I
Seat and Fender — Model No. 247.28672
J
Ref.
No.
Part No. Description
1 683-04223-0637 Lift Shaft Assembly
2 712-04063 Flangelock Nut, 5/16-18
3 712-04065 Flangelock Nut, 3/8-16
4 914-0104 Cotter Pin, .072 DIA. X 1.13LG
5 714-04040 Bow-Tie Cotter Pin
6 716-0106A E-Ring, .625 DIA. SHAFT
7 720-04150 Handle Grip
8 732-0874 Torsion Spring
9 736-0105 Spring Washer, .401 X .870 X .063
10 738-0138A Shoulder Screw, .437 X .470:5/16-18
11 738-04130 Shoulder Bolt, .625X.175:3/8-16
12 941-0225 Hex Flange Bearing
13 746-0968 Lift Cable, 16.16 LG
14 747-04962A Lift Handle
15 756-04331 Pulley Roller Cable
16 783-04494C-0637 RH Lift Arm
—
783-04711C-0637 LH Lift Arm
17 710-04482 Hex Head Flange, 3/8-16:.875
18 710-04484 Taptite Screw, Lock Washer, 5/16-18:.750
19 712-3004A Flangelock Nut, 5/16-18
20 725-0157 Cable Tie, 3/16 X .05X7.4
Ref.
No.
Part No. Description
21 732-04561 Compression Spring, 1.71 X 3.735 X .238
22 732-04563 Compression Spring, .68 X 1.065 X .055
23 938-0296 Shoulder Screw, .437 X .268:5/16-18
24 783-06049-0691 Seat Mounting Bracket
25 783-06050 Seat Adjustment Lever
26 783-06088-0691 Seat Pivot Bracket
27 783-06448 Switch Retainer Clip
28 710-04187 Hi-Lo Screw, Lock Washer, 1/4-15:0.50
29 710-0451 Carriage Bolt, 5/16-18:.750
30 710-0599 Taptite Screw, Lock Washer, 1/4-20:0.500
31 710-0895 Hi-Lo Screw, Lock Washer, 1/4-15:0.750
32 731-05837 LH Fender Cover
33 731-06754 RH Fender Cover
34 736-3078 Flat Washer, .344 X 1.00 X .063 HDN
35 783-06118-0691 Fender
36 726-3046 Ratchet Clip
37 735-04137 LH Foot Pad
—
735-04139 RH Foot Pad
38 757-04127 Seat
39 783-06181-0637 Lift Bracket
40 925-05013 Seat Switch
