TRACTOR - > MODEL NUMBER 917^1910
GROUND DRIVE
KEY PART KEY PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
1 Transaxle (See Breakdown) 65 STD551143 Washer
Peerless206~545C 66 154778 Keeper, Belt, Engine, Fool-Proof
2 146682 Spring, Return, Brake 70 134683 Guide, Mower Drive Belt, R.H.
3 123666X Pulley, Transaxle 74 137057 Spacer, Axle
4 12000028 Ring, Retainer 75 121749X Washer 25/32 x 1-1/4 x 16 Ga.
5 121520X Strap, Torque 76 STDseiore E-Ring
6 17060512 Screw 5/16-18x3/4 77 123583X Key, Square 2.0 x .1845/.1865
8 165866 Rod Shifter Fender STLT 78 121748X Washer 25/32 x 1-5/8 x 16 Ga
10 SH)561210 Pin, Cotter 79 STD5800(25 Key Woodruff
11 105701X Washer, Shift Plate 80 145090 Arm, Shift
13 74550412 Bolt 1/4-26 UNF W/Patch Gr. 8 81 165592 Shaft Asm Cross Tapered
14 10040400 Washer Lock Hvy Helical 82 165711 Spring, Torsion
18 STD523710 Boit Fin Hex 3/8-16UNC X1 Gr 5 83 19171216 Washer 17/32 x 3/4 x 16 Ga.
19 STD541437 Nut 84 166231 Link Transaxle
21 106933X Knob 85 150360 Nut, Nylock
22 130804 Rod, Brake 89 158391X428 Console, Shift, STLT
24 STD541237 Nut 90 124346X Nut, Self-Thding, Wsh Hd 1/4
25 106888X Spring, Brake Rod 96 STD624003 Retainer Spring 1*
26 STD551037 Washer 112 19091210 Washer 9^ x 3/4 x 10 Gauge
27 STD561210 Pin 113 127285X Strap Torque 90 Degrees
28 175765 Rod, Parking Brake 116 72140608 Bon Rdhd Sqneck 3/8-16 x 1
29 71673 Cap, Parking Brake 120 73900600 Nut Lock Rg. 3/8-16
30 169592 Bracket, Transaxle 145 74490540 Bon, Hex Rghd 5/16-18 Gr. 5
32 STD523107 Bolt 150 175456 Spacer Retainer
34 175578 Shaft Assembly, Foot Pedal 151 19133210 Washer 13/32 x 2 x 10 Ga.
35 120183X Bearing, Nylon 156 166002 Washer Srrted 5/16iD X 1.125
36 STD551062 Washer 158 165589 Bracket Shift Mount
37 STD571810 Roll Pin 159 165494 Hub Tapered Flange Shift Lt
38 179114 Pulley, Composite 161 72140406 Bon Rdhd Sqnk 1/4-20 x 3/4 Gr.5
39 74760648 Bolt, Rn Hex 3/8-16 x 3 162 73680400 Nut Crownlock 1/4-20 Unc
41 175556 Keeper, Belt, Idler 163 74780416 Bon Hex Rn 1/4-20Unc x 1 Gr 5
47 127783 Pulley, Idler, V-Gtoove, Plastic 164 19091010 Washer 5/8 x .281 x 10 Ga
48 154407 Bellcrank Clutch Gmd Drv Stt 165 165623 Bracket Pivot Lever
49 123205X Retainer, Belt 166 166860 Screw 5/16-18 x 5/8
50 STD523715 Boit Hex Hd 3/8-16x1-1/2 168 165492 Bott Shoulder 5/16-18 x .561
51 STD541437 Nut Crown Lock 3/8-16 UNC 169 165580 Plate Fastening Lt
52 STD541431 Nut Crown Lock 5/16-18 UNC 170 173894 Keeper Belt Transaxle Gear
53 10571OX Link, Clutch 197 169613 NylinerSnap-ln
55 105709X Spring, Clutch Return 198 169593 Washer Nyliner
56 17060620 Screw 3/8-16x1-1/4 202 72110614 Bon Carr. SH 3/8-16 X 1 -3/4 Gr. 5
57 130801 V-Belt, Ground Drive 212 145212 Nut Hex Rg. Lock
59 169691 Keeper, Belt, Center Span
61 17120614 Screw 3/8-16X.875
62 8883R Cover, Pedal
63 175410 Pulley, Engine
64 71170764 Bolt, Hex 7/16-20 X 4 Grade 5 NOTE: All component dimensions given in U. S,
inches 1 inch = 25.4 mm
37
