Operating features – Wood’s Powr-Grip PT410AC User Manual
Page 5
Rev 11.3/2-13
3
PT410AC: #35140
OPERATING FEATURES
Note: Components featured in the following instructions for assembling, operating or
maintaining the vacuum lifter are underlined on their first appearance in each section.
Standard PT410AC shown.
1 LIFT SPOOL
6 VACUUM GAUGE
12 PAD FRAME
2 POWER SWITCH
7 AIR FILTER
13 VACUUM RELEASE BUTTON
3 VACUUM LIFT LIGHT
8 VACUUM PAD
14 MOVABLE CONTROL PENDANT
4 LIFT BAR
9 ALTERNATIVE LOCATION FOR PENDANT
15 TILT TOGGLE SWITCH
5 Enclosure with
10 VACUUM RESERVE TANK
16 VACUUM PUMP
VACUUM SWITCH
11 CONTROL HANDLES
17 TILT ACTUATOR
