3
MTA8LP6FAIR: #35096
OPERATING FEATURES
Note: Components featured in the following instructions for assembling, operating or
maintaining the vacuum lifter are underlined on their first appearance in each section.
Standard MTA8LP6FAIR shown.
1 LIFT SPOOL
5 VACUUM PAD
9 SLIDING ADJUSTABLE PAD MOUNT
2 AIR FILTERS
6 PAD FRAME
10 VACUUM PUMP (VENTURI)
3 VACUUM GAUGE
7 VACUUM RELEASE BUTTON
11 AIR SUPPLY VALVE
4 LIFT BAR
8 CONTROL HANDLES
12 AIR PRESSURE REGULATOR
