Rev 2.0/12-12 10 MTA8LP6FAIR: #35096
T
O
L
IFT AND
M
OVE THE
L
OAD
About the Tilt Linkage
WARNING: Make sure load is positioned correctly on lifter; unbalanced loads
may tilt unexpectedly.
The lifter’s tilt linkage is designed to automatically hold a balanced load in either the upright or
the flat position. However, an unbalanced load may tilt unexpectedly from the flat position to the
upright position or vice versa, when lifted. This could result in load damage or injury to anyone
positioned in the tilt path of the load. To minimize the potential for these problems, make certain
prior to lifting any load that it has allowable characteristics (see INTENDED USE: L
OAD
C
HARACTERISTICS
) and is attached correctly to the lifter (see T
O
A
PPLY THE
P
ADS TO A
L
OAD
preceding).
Load Capacity and the Vacuum Gauge
A lifter’s Load Capacity is rated at a vacuum level of 16" Hg [-54 kPa] (see SPECIFICATIONS).
Vacuum higher than this level registers in the green range on the vacuum gauge, to indicate that
the lifter is ready to lift the maximum load weight.
WARNING: Never attempt to lift load unless vacuum level registers higher than
16" Hg [-54 kPa].
Do not attempt to lift the load while vacuum registers lower than 16" Hg [-54 kPa]; such an
attempt could result in a load release and possible injury to the operator.
Monitoring the Vacuum Gauge
The vacuum gauge must remain completely visible to the operator, so that it can be monitored
throughout the entire lift.
WARNING: Vacuum gauge must be visible to operator throughout entire lift.
The lifter’s vacuum pump runs continuously to maintain sufficient vacuum for lifting the
maximum load weight. If the vacuum system experiences leakage while the lifter is attached to
the load, the vacuum gauge signals the reduction in vacuum to the operator. Make sure the
vacuum gauge shows a vacuum level of 16" Hg [-54 kPa] or higher while you are lifting a load.
If not, move away and stay clear of the load until it can be lowered to the ground or a stable
support.
WARNING: Stay clear of any suspended load while vacuum level is lower than
16" Hg [-54 kPa].
Discontinue lifter use until the cause of the vacuum loss can be determined. If the vacuum level
remains lower than 16" Hg [-54 kPa] when the lifter is attached to clean, smooth, nonporous
materials, the leakage is likely to be in the vacuum system. In this event, perform the V
ACUUM
T
EST
(see MAINTENANCE) and inspect the vacuum pads for damage (see MAINTENANCE: V
ACUUM
P AD M AINTENANCE : Inspection). If the vacuum loss cannot be remedied immediately, perform
inspection and maintenance as needed to identify and correct any deficiency before resuming
normal operation of the lifter.
