Rev 8.0/6-13 13 MRTALPCH6-DC: #35054
CAUTION: Examine each air filter regularly, and empty when necessary.
Two air filters help protect the vacuum generating system from contaminants. However, the
lifter is not intended for use on wet load surfaces because the filters would not prevent liquid
from entering the vacuum system. The operator must examine each filter regularly and remove
any liquid or other contaminants found inside (see MAINTENANCE: A
IR
F
ILTER
M
AINTENANCE
). To
access the air filters, remove the cover indicated in OPERATING FEATURES.
Confirming the Pad Frame Configuration
WARNING: Load capacity of lifter can vary, depending on pad frame
configuration.
Make sure the pad frame has been assembled in the configuration that will provide optimal
support of the load while lifting (see ASSEMBLY: T
O
C
HANGE THE
P
AD
F
RAME
C
ONFIGURATION
). The
pad frame configuration selected must be appropriate, both for the weight and for the
dimensions of the load in question.
Preparing to Use the Optional Remote Control System
If the lifter is equipped with a Remote Control System, the operator can engage the lifter's apply
and release functions at distances up to 250 ft [76 m], provided there is a direct and clear view
of the lifter and its status indicators from the operator location (see MAINTENANCE: R
EMOTE
C
ONTROL
S
YSTEM
T
EST
). When lifting a load from a remote location, the operator must monitor
the lifter at all times to make sure that it is functioning as intended. 7 In addition, the operator
must exercise special care to ensure that the load is landed and supported correctly before
releasing the load (see T
O
R
ELEASE THE
P
ADS FROM THE
L
OAD
to follow).
The radio transmitter is also equipped with an emergency transmitter disconnect that prevents
the transmitter from sending any transmission. This button should not need to be used, but
may have to be reset if accidentally engaged. To reset, twist the button clockwise while
allowing it to spring outward to its normal position.
7
The Remote Control System is designed with safeguards to prevent multiple lifters from responding until a clear transmission
is received. Nevertheless, radio controlled lifters should be tested to ensure that each transmitter controls only one lifter. The
buttons located on the lifter function regardless of any radio transmissions in the vicinity.
