To Install/Remove Pad Frame Extensions
1) Set the lifter with the vacuum pads facing downward on a clean, smooth, flat surface.
2) Insert the tabs extending from one pad frame extension between the rails of the pad frame.
If the tabs do not fit between the rails, you may loosen the bolts that connect the tabs to the
extension. Make sure that the vacuum pads on the extension and on the pad frame are
contacting the same surface, to ensure that all the pads are aligned in the same plane.
Note: The pad frame extension that is equipped with a control handle should be installed on
the lower end of the pad frame (ie, when oriented vertically).
3) Align the bolt holes in the pad frame extension with the bolt holes in the pad frame.
4) Secure the pad frame extension in the pad frame by installing the bolts supplied and
tightening all bolts securely.
5) Connect the vacuum hose to the vacuum pad on the pad frame extension as directed in the
preceding section, To Connect/Disconnect Vacuum Hoses.
6) Repeat steps 1-5 to install the other pad frame extension.
7) To remove pad frame extensions, reverse this procedure. Store removed extensions in a
clean, dry location, to protect them from environmental exposure. Use the pad covers
supplied to keep the vacuum pads clean.
